  • 产品名称: MONITOR BOX OVEN


  • 1.      Nominal volume: Size can be made according to customer’s requirement.
    2.      Max using temperature 250˚С
       Normal using temperature:  room temperature 20~200˚С.
    3.      Temperature control accuracy:  ±1˚С
    4.      maximum heating rate, ˚С/hr: 60;
    5.      maximum using temperature:100 section
    6.      Out wall temperature: ≤ room temperature+20˚С.
    7.      Ther is safety and alarm system
    8.      Monitoring system(selected part)

Messages Contact

1.      Nominal volume: Size can be made according to customer’s requirement.
2.      Max using temperature 250˚С
   Normal using temperature:  room temperature 20~200˚С.
3.      Temperature control accuracy:  ±1˚С
4.      maximum heating rate, ˚С/hr: 60;
5.      maximum using temperature:100 section
6.      Out wall temperature: ≤ room temperature+20˚С.
7.      Ther is safety and alarm system
8.      Monitoring system(selected part)


  Model SMY-I SMY-II SMY-III SMY-IV
Heart Dimension(mm) 1000×1000×1000 1700×1700×1100 1800×1700×1820

4700×1300×1500
Heart Volume(M3 1 3 5 9
Heating Power(kW ) 14.4 22 28.8 57
Furnace inside Temperature(℃) Rising Section≤± 4℃     Soaking Section≤± 2 ℃ Rising Section≤± 4℃     Soaking Section≤±2℃ Rising Section≤±5℃     Soaking Section≤± 3℃ Rising Section≤±5 ℃     Soaking Section≤±3℃

The loading capacity is calculated on the Φ400 mm cutting wheels.
History data can be record. One set of center monitoring system can control 1~6 number of box ovens.






Key words : MONITOR,BOX,OVEN,Nominal,volum
